Refrigerated Container Ramp 2400mm Length

The Refrigerated Container Ramp is designed primarily for bridging into a standard container from ground level for loading and unloading a shipping container utilising a forklift. The Refrigerated Container Ramps can also be used for vehicle loading from a raised dock. CRR2400 Refrigerated Container Ramp is a fully welded steel container ramp purposely built for Refrigerated Containers only. This Refrigerated Container Ramp has an overall height of 210mm which is 50-60mm higher than a standard ramp to suit the high entry point of a reefer container. The Refrigerated Container Ramp has side entry pockets with 6mm anti-slip cheque plate.
Part No: CR5-2400-R
*
Call for pricing

The Refrigerated Container Ramp is designed primarily for bridging into a standard container from ground level for loading and unloading a shipping container utilising a forklift. The Refrigerated Container Ramps can also be used for vehicle loading from a raised dock.

HE-CR5-2400-R Refrigerated Container Ramp is a fully welded steel container ramp purposely built for Refrigerated Containers only. This Refrigerated Container Ramp has an overall height of 210mm which is 50-60mm higher than a standard ramp to suit the high entry point of a reefer container. The Refrigerated Container Ramp has side entry pockets with 6mm anti-slip cheque plate.

  • Length 2400mm (Slope section 1200mm, Flat section1200mm)
  • Width 2200mm
  • Heights 210mm
  • 6mm Anti-slip Chequer plate
  • Painted finish (PA10)
  • SWL 5000kgs
  • Side entry fork pockets
  • Unit Weight: 430kg
  • Securing chains
